Sprint Backlog 04

{
  "version": 3,
  "configurePresets": [
    {
      "name": "default",
      "generator": "Visual Studio 17 2022",
      "architecture": "x64",
      "toolchainFile": "$env{VCPKG_ROOT}/scripts/buildsystems/vcpkg.cmake",
      "binaryDir": "build",
      "cacheVariables": {
        "X_VCPKG_APPLOCAL_DEPS_INSTALL": true
      }
    }
  ]
}

if(APPLE)
    install(CODE "
        # make sure the bundle is already on disk
        set(BU_CHMOD_BUNDLE_ITEMS TRUE)
        include(BundleUtilities)

        # full path to the real executable inside the bundle
        set(app_exe \"\${CMAKE_INSTALL_PREFIX}/OreStudio.app/Contents/MacOS/OreStudio\")

        # directory where 3rd-party libraries will be copied
        set(libs_dir \"\${CMAKE_INSTALL_PREFIX}/OreStudio.app/Contents/Frameworks\")

        # discover all prerequisites and copy/fix them
        fixup_bundle(\"\${app_exe}\" \"\" \"\${libs_dir}\")
    " COMPONENT Runtime)
endif()

function(add_catch2_tag_target test_exe tag)
    string(REPLACE "[" "" clean_tag "${tag}")
    string(REPLACE "]" "" clean_tag "${clean_tag}")
    add_custom_target(test-${clean_tag}
        COMMAND ${test_exe} "${tag}"
        DEPENDS ${test_exe}
        WORKING_DIRECTORY ${CMAKE_CURRENT_BINARY_DIR}
    )
    # Optional: register with CTest
    add_test(NAME ${test_exe}_${clean_tag} COMMAND ${test_exe} "${tag}")
endfunction()

# Usage:
add_catch2_tag_target(my_app_tests "[repository]")
add_catch2_tag_target(my_app_tests "[comms]")

inline std::tm* safe_localtime(const std::time_t* time, std::tm* result) {
#ifdef _WIN32
    return localtime_s(result, time) == 0 ? result : nullptr;
#else
    return localtime_r(time, result);
#endif
}

Yes — but only if you **keep the same ownership rule in both states** (attached *and* detached).
The moment you let Qt parent the widget **and** still keep it in a container that you later `delete`, you again have **two owners**, and the double-delete will come back as soon as the user re-attaches the window and then quits the program.

Below is the minimal change that lets the user detach/reattach as often as he wants **and** guarantees that the object is destroyed **exactly once**.

--------------------------------------------------------
1.  Pick one unique owner
--------------------------------------------------------
Make **MainWindow** the unique owner.
That means:

- Never give the widget a parent (pass `nullptr` in the constructor).
- Always insert it into one of the four containers.
- Delete it **only** from those containers (or when the user explicitly closes
  it).
- When the widget is *attached* to the MDI area, use
  **QMdiArea::addSubWindow()**; this only sets the **QMdiSubWindow** as parent
  of the **internal viewport**, **not** of your custom widget, so your widget
  stays parent-less.

Code sketch:

```cpp
// create
auto w = new CurrencyMdiWindow(nullptr);          // no parent
mdiArea->addSubWindow(w);                         // only the QMdiSubWindow gets a parent
currencyDetailWindows_.insert(iso, w);
allDetachableWindows_.append(w);
```

--------------------------------------------------------
2.  Remove it from the lists at the right moment
--------------------------------------------------------
As soon as the widget dies (user presses ×, or you programmatically close it) you must **erase the pointer** from every container; otherwise you will dereference a dangling pointer when you later iterate over the lists.

Connect once, right after creation:

```cpp
connect(w, &QObject::destroyed, this, [this, w](QObject* o) {
    Q_UNUSED(o)
    currencyDetailWindows_.remove(w->isoCode());
    allDetachableWindows_.removeAll(w);
    /* same for the other three maps/lists */
});
```

--------------------------------------------------------
3.  Detach / re-attach implementation
--------------------------------------------------------
Detaching simply reparents to **nullptr** and shows the widget as top-level:

```cpp
void MainWindow::detachWindow(QWidget* w)
{
    w->setParent(nullptr);
    w->show();
}
```

Re-attaching puts it back into the MDI area:

```cpp
void MainWindow::attachWindow(QWidget* w)
{
    w->setParent(nullptr);              // make sure it is still parent-less
    mdiArea->addSubWindow(w);
    w->show();
}
```

Because the widget **never** had a Qt parent, Qt will **never** auto-delete it; only your own code (or the user closing the top-level window while `Qt::WA_DeleteOnClose` is set) can trigger the `destroyed()` signal, and that signal already removed the pointer from the lists.

--------------------------------------------------------
4.  Destructor becomes trivial
--------------------------------------------------------
```cpp
MainWindow::~MainWindow()
{
    // delete every widget that is still alive
    qDeleteAll(currencyDetailWindows_);
    qDeleteAll(currencyHistoryWindows_);
    delete currencyListWindow_;
    qDeleteAll(allDetachableWindows_);
}
```

Each widget is deleted **once**, the `destroyed()` lambda runs immediately and clears the lists, so when the next container is destroyed its `qDeleteAll` sees only `nullptr`s (or the map is already empty).

--------------------------------------------------------
5.  Optional extra safety
--------------------------------------------------------
If you want to be 100 % sure, store **QPointer** in the containers instead of raw pointers:

```cpp
QMap<QString, QPointer<DetachableMdiSubWindow>> currencyDetailWindows_;
```

Now the destructor can even be written as

```cpp
for (auto it = currencyDetailWindows_.begin(); it != currencyDetailWindows_.end(); ++it)
    delete it.value();   // safe: delete nullptr is a no-op
```

but this is **not required**—the design above is already bullet-proof.

--------------------------------------------------------
Summary
--------------------------------------------------------
- Pick **one** owner (MainWindow).
- Keep widgets **parent-less**.
- Add / remove them from the lists **synchronously** via `destroyed()`.
- Detach/reattach only changes **visual** parent, not ownership.

With these rules you can detach and re-attach as often as you like, and the
program will still shut down without the heap corruption you are seeing now.

[marco@lovelace bin]$ ./ores.qt
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_currency_dollar_euro_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_history_20_regular.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_plug_disconnected_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_plug_connected_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_edit_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_delete_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_save_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_document_table_20_regular.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_document_code_16_regular.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_star_20_regular.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_plug_connected_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_plug_disconnected_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_plug_connected_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_plug_disconnected_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_currency_dollar_euro_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_save_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_edit_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_delete_20_filled.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_document_table_20_regular.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_document_code_16_regular.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_star_20_regular.svg', because: No such file or directory
qt.svg: Cannot open file '/opt/OreStudio/0.0.4/bin/ic_fluent_history_20_regular.svg', because: No such file or directory

To make your Qt application look like an advanced trading system—even for a
simple CRUD operation screen—requires moving beyond basic desktop application
styles toward the dense, high-contrast, data-rich aesthetic of platforms like
Bloomberg or professional broker terminals.

The current look (a dark table with simple data rows) is a great foundation.
Here are targeted suggestions for your Qt UI to elevate it to a professional,
advanced trading system aesthetic:

## I. Color and Contrast (The Dark Theme)

Your current dark gray background is good, but trading systems use specific
contrast to highlight data significance.

1.  **Define a Palette:** Adopt a limited, functional color palette:

      * **Primary Background:** A very dark, near-black charcoal (`#1A1A1A` or
        `#1E1E1E`). This is the foundation.
      * **Foreground/Text:** Clean white or light gray (`#F0F0F0`).
      * **Accent Color (Neutral):** A subdued corporate blue/cyan (`#007ACC` or
        a subtle green/gold from your branding) for selected rows, borders, and
        input focus.
      * **Data Status Colors:**
          * **Positive (Gains):** Bright, high-contrast green (`#00C853`).
          * **Negative (Losses):** High-contrast red (`#FF3333`).
          * *(While CRUD isn't about gains/losses, you can use these colors for
            status, like 'Active' vs. 'Inactive' currencies).*

2.  **Subtle Depth:** Avoid flat black. Use a slightly lighter shade of gray
    (`#2A2A2A`) for embedded panels, sidebars, and control areas to create
    visual segmentation, giving the impression of modularity.

## II. Typography and Data Presentation

Trading UIs prioritize density and scannability.

1.  **Monospace Font:** For the currency codes and numerical columns, switch to
    a clear, legible **monospace font** (like Consolas, Fira Code, or a custom
    font in Qt). Monospace fonts ensure that all numbers align perfectly in
    columns, which is essential for rapid data comparison.
2.  **Font Sizing:** Use a small, consistent font size (e.g., 10pt or 11pt) to
    fit more data on screen. Use bolding sparingly, primarily for the Currency
    Code (e.g., USD, EUR).
3.  **Visual Alignment:**
      * **Text Columns** (Currency Name): Left-aligned.
      * **Code Columns** (ISO Code, Symbol): Center-aligned.
      * **Numerical Columns** (Rounding, Precision): Right-aligned. **This is
        critical** for financial UIs, as it allows users to compare magnitude
        instantly.

## III. Advanced Table View Enhancements (QTableView/QTableWidget)

Since the core of this screen is a table, focus on making the table look
high-tech.

1.  **Header Styling:**

      * Make column headers slightly stand out with a subtle dark gradient or a
        distinct, slightly brighter background color (e.g., `#282828`).
      * Ensure the header font is crisp (perhaps slightly bolder than the row
        data).
      * Add tiny, clear **sort indicators** to show the current sort direction.

2.  **Row Selection:**

      * The selected row should use your accent color (e.g., a thin blue left
        border or a light blue background fill) with white or light gray text
        for high visibility.
      * Introduce **subtle, faint horizontal rules** (1px in a color like
        `#333333`) to separate rows, which aids readability in dense tables.

3.  **Interactive Elements (Hover):** Implement a very subtle change on row
    hover (e.g., the background darkens by 5%) to indicate interactivity, even
    if clicking doesn't change the view.

## IV. UI Layout and Modularity

Advanced UIs are rarely monolithic; they are built from modular panels.

1.  **Toolbar (Top):** Create a clean, dedicated toolbar area at the top for
    your CRUD operations (`Add`, `Edit`, `Delete`) and your system icons
    (Connection, Reference Data).

      * Use the Fluent UI System Icons you researched (`globe-32-regular`,
        `money-32-regular`).
      * Buttons should be flat, high-contrast text or icons only. On hover, they
        should reveal a subtle gray background or a thin accent border.

2.  **Side Panel (Right or Left):** Instead of a simple dialog for *editing*,
    use a dedicated side panel that slides out or appears next to the table when
    a row is selected.

      * This panel would house the detail view for the selected currency. This
        makes the UI feel like a single workspace rather than navigating modal
        windows.
      * Give this panel a slightly different background shade (`#2A2A2A`).

3.  **Status Bar (Bottom):** Add a sleek, minimal status bar at the bottom. This
    is where you would place your connection status icon (using your proposed
    `globe-32-regular` or `plug-connected-32-regular` icon). It reinforces the
    "system is live" feel.

## V. Qt-Specific Implementation via Stylesheets

In Qt, you achieve this professional look primarily through **QSS (Qt Style
Sheets)**. You will be targeting specific widgets (like `QTableView`,
`QPushButton`, `QLineEdit`) with CSS-like rules.

```css
/* Example QSS Snippets for the Trading Look */

QTableView {
    /* Base style for the data area */
    background-color: #1A1A1A; /* Primary Background */
    gridline-color: #333333; /* Faint row separators */
    color: #F0F0F0;
    border: 1px solid #007ACC; /* Subtle border using accent color */
    selection-background-color: #007ACC; /* Accent Color for selection */
    selection-color: white;
}

QHeaderView::section {
    /* Style for Column Headers */
    background-color: #282828; /* Slightly lighter shade for headers */
    color: #FFFFFF;
    border: none;
    padding: 6px;
    font-size: 11pt;
    font-weight: bold;
}

QLineEdit {
    /* Style for input fields (e.g., in the side panel or search) */
    background-color: #1A1A1A;
    border: 1px solid #444444;
    color: #F0F0F0;
    padding: 5px;
}

QPushButton {
    /* Flat button style for toolbar */
    background-color: transparent;
    border: none;
    color: #F0F0F0;
    padding: 8px 12px;
}

QPushButton:hover {
    /* Hover effect */
    background-color: #2A2A2A;
    border: 1px solid #007ACC;
}
```

root@lovelace:~# apt install /home/marco/Downloads/orestudio_0.0.4_amd64.deb
You might want to run 'apt --fix-broken install' to correct these.
Unsatisfied dependencies:
 orestudio : Depends: libqt6gui6t64 (>= 6.1.2) but it is not installable
             Depends: libqt6widgets6t64 (>= 6.1.2) but it is not installable
Error: Unmet dependencies. Try 'apt --fix-broken install' with no packages (or specify a solution).
root@lovelace:~# apt install libqt6widgets6t64 libqt6gui6t64
Package libqt6gui6t64 is not available, but is referred to by another package.
This may mean that the package is missing, has been obsoleted, or
is only available from another source
However the following packages replace it:
  libqt6gui6:i386  libqt6gui6


Package libqt6widgets6t64 is not available, but is referred to by another package.
This may mean that the package is missing, has been obsoleted, or
is only available from another source
However the following packages replace it:
  libqt6widgets6:i386  libqt6widgets6


Error: Package 'libqt6widgets6t64' has no installation candidate
Error: Package 'libqt6gui6t64' has no installation candidate

[marco@lovelace ~]$ /opt/OreStudio/0.0.4/bin/ores.qt
terminate called after throwing an instance of 'boost::filesystem::filesystem_error'
  what():  boost::filesystem::create_directories: Permission denied [system:13]: "/home/marco/../log", "/home/marco/../log"
Aborted                    /opt/OreStudio/0.0.4/bin/ores.qt
