badge_definition Struct Reference

Visual definition for a badge, including colours, label, and severity. More...

#include <badge_definition.hpp>

Collaboration diagram for badge_definition:

Public Attributes
int	version = 0
	Version number for optimistic locking and change tracking.
utility::uuid::tenant_id	tenant_id = utility::uuid::tenant_id::system()
	Tenant identifier for multi-tenancy isolation.
std::string	code
	Unique badge definition code.
std::string	name
	Display label shown inside the badge.
std::string	description
	Tooltip text explaining what this badge represents.
std::string	background_colour
	Badge background colour as a hex string.
std::string	text_colour
	Badge text colour as a hex string.
std::string	severity_code
	Severity classification for this badge.
std::string	css_class
	Optional Bootstrap CSS class hint for Wt rendering.
int	display_order
	Order for UI display purposes.
std::string	modified_by
	Username of the person who last modified this badge definition.
std::string	performed_by
	Username of the account that performed this action.
std::string	change_reason_code
	Code identifying the reason for the change.
std::string	change_commentary
	Free-text commentary explaining the change.
std::chrono::system_clock::time_point	recorded_at
	Timestamp when this version of the record was recorded.

Detailed Description

Visual definition for a badge, including colours, label, and severity.

The badge catalogue. Each entry defines the complete visual presentation of a badge: display label, tooltip, background colour, text colour, severity level, and an optional Bootstrap CSS class hint for Wt.

Badge definitions are the single source of truth for all badge visual metadata across Qt and Wt. They are loaded at client startup as reference data and looked up at render time via BadgeCache.

Member Data Documentation

code

std::string code

Unique badge definition code.

Examples: 'active', 'locked', 'fsm_draft', 'login_online'.

background_colour

std::string background_colour

Badge background colour as a hex string.

Example: '#22c55e'.

text_colour

std::string text_colour

Badge text colour as a hex string.

Default is '#ffffff' (white). May vary for light-background badges.

severity_code

std::string severity_code

Severity classification for this badge.

Soft FK to ores_dq_badge_severities_tbl. Bootstrap-aligned codes: secondary, info, success, warning, danger, primary.

css_class

std::string css_class

Optional Bootstrap CSS class hint for Wt rendering.

Example: 'badge bg-success'. Qt ignores this field. Nullable — Wt falls back to inline style from background_colour/text_colour when absent.

change_reason_code

std::string change_reason_code

Code identifying the reason for the change.

References change_reasons table (soft FK).
