ores.scheduler.core

ores.scheduler.core provides cron-based job scheduling for ORE Studio. It manages job definitions (cron expressions, target actions) and job instances (execution history, status), runs a persistent scheduler loop that fires due jobs, and exposes NATS handlers for querying and managing jobs at runtime. It supports SQL and NATS-publish action types, making it the general-purpose periodic-operation backbone for the platform.

The job-definition entity stack – repository, mapper, entity, service, handler, sub-registrar, history provider and the presentation field mapper – is generated from the entity model. The hand-written code here is the infrastructure generation does not reach: the scheduler loop, the cron evaluator, the action handlers, the messaging registrar that composes the generated sub-registrar with the two hand-written view handlers, and the job-instance repository.

• NATS request messages for job-definition CRUD, the version reads, the two operational views, and the executions the loop serves.
• PostgreSQL connections to ores_scheduler_* tables for job persistence.
• System clock for evaluating cron expressions.

• Job-definition and job-instance records persisted to the ores_scheduler schema.
• Triggered actions: SQL statements executed, or NATS messages published, per job schedule.
• NATS response messages returned to callers, and a change event per job definition write.

• include/ores.scheduler.core/ores.scheduler.hpp — namespace documentation.
• include/ores.scheduler.core/messaging/registrar.hpp — composes every NATS handler the component serves: the generated job-definition registrar, the two view handlers, and the generic history handler.
• include/ores.scheduler.core/messaging/job_definition_registrar.hpp — the generated job-definition handlers.
• include/ores.scheduler.core/messaging/job_instance_handler.hpp — the global job-instance list.
• include/ores.scheduler.core/messaging/scheduler_status_handler.hpp — the live scheduler status.
• include/ores.scheduler.core/service/scheduler_loop.hpp — the main scheduling loop driven by the service host.

• ores.scheduler.api — domain types, the generated protocol, and the generated entity artefacts.
• ores.database — connections, the request context, and the bitemporal repository operations.
• ores.nats — NATS client, subscriptions and wire codec.
• ores.service — request context, handler helpers and permission checks.
• ores.history.core — the generic history provider registry.
• ores.eventing.api — the change event published when a job fires.
• ores.utility, ores.security, ores.logging, ores.platform — shared types, token validation, logging and time formatting.
• croncpp — cron expression parsing and next-occurrence computation.
• libfort — the table rendering of the domain types.

What the shared profile cannot know, declared here rather than hand-edited into the generated build file. Each block is spliced into its generated file after the profile's baseline.

• ores.scheduler — component group overview.
• ores.scheduler.api — protocol types and domain entities.
• ores.scheduler.service — NATS service entrypoint.
• ores.scheduler Messaging Reference — full NATS subject and message catalogue.

The suites link what the profile cannot know about.

target_link_libraries(${lib_target_name}
    PUBLIC
        ores.scheduler.api.lib
        ores.database.lib
        ores.nats.lib
    PRIVATE
        ores.eventing.api.lib
        ores.history.core.lib
        ores.service.lib
        ores.utility.lib
        ores.security.lib
        ores.logging.lib
        ores.platform.lib
        croncpp::croncpp
        libfort::fort)

target_link_libraries(${tests_target_name}
    PRIVATE
        ${lib_target_name}
        ores.eventing.api.lib
        ores.eventing.core.lib
        ores.nats.lib
        ores.refdata.core.lib
        ores.telemetry.core.lib
        ores.utility.lib
        ores.testing.lib
        ores.logging.lib
        Catch2::Catch2
        faker-cxx::faker-cxx
        ores.openssl_cleanup
        Threads::Threads)
